TECHNICAL PARAMETER (AC SERIES)

Category: Air Filters

Brand: Zakf

**TECHNICAL PARAMETER**
Standard Model	Capacity m³/MIN	Voltage AC	Power KW	Current A	Refrigerant Type	Caliber of Tube (Inlet and out)	Weight KG	Dimension LWH
AC-10	1.5	1 0420V	0.37	3.7	R22	1″PT	60	700450780
AC-20	2.8		0.74	6.3		1 1/2″PT	70	760460780
AC-30	5.0		1.48	6.70		80	830570860
AC-50	7.8		2.98	8.70		2″PT	100	1030570860
AC-70	12.5		4.3	10.70		120	1200570860
AC-100	13.0	3 0380V	1.94	10.70	R134A	2″PT	200	13007001230
AC-150	15.0		2.57	13.60		230	13007001230
AC-200	25.0		3.10	8.60		DN80	350	15008001460
AC-280	28.0		4.40	12		400	15008001460
AC-300	35.0		5.78	15		DN100	550	20009001640
AC-400	45.0	50HZ	6.61	19	DN125	700	210010501640
AC-450	55	8.62	20	DN125	730	210010501640
